Visiblewave VK4L 4 Output MK4 Sky Digital Quad LNB with PLL Technology

Highlights

Finished in grey
Supplied with a SkyTM compatible bracket
Built-in spirit level
Includes 25MHz PLL crystal technology to ensure rock-solid frequency stability across a wider range of operating temperatures

Specifications:

Input frequency
Low band: 10.7~11.7GHz
High band: 11.7~12.75GHz

Output frequency
Low band: 950~1950MHz
High band: 1100~2150MHz

L.O. stability
+/- 1.0MHz @ 25°C
+/- 3.0MHz @ -30°C~ +60°C

Phase noise
-50dBc/hz @ 1kHz
-75dBc/hz @ 10kHz
95dBc/hz @ 100kHz

L.O. frequencies: 9.75/10.6GHz
Noise gure: 0.5dB (Typ)
Conversion gain: 55dB (min)/65dB (max)
Gain atness: 0.75dB (min)/26MHz (max)
Cross polar isolation: 25dB (Typ)
Image rejection: 40dB (min)
Operating temperature: -30°C~ +60°C
Power consumption: 200mA (max)
RED compliance: EN 303 372-1

Legal Disclaimer
This LNB is not manufactured, endorsed or sold by Sky™ or Freesat™
