Citronic D-Series Class-D Power Amplifier 2×1200W RMS Professional PA 1U

Citronic D-Series Class-D Power Amplifier – 2×1200W RMS

The Citronic D-Series is a powerful and lightweight 1U rack-mountable Class-D stereo power amplifier, designed for professional sound reinforcement applications. With 2×1200W RMS at 4Ω, selectable operating modes and a built-in limiter, it provides high output performance in a compact format.

Key Features

2×1200W RMS @ 4Ω
2×800W RMS @ 8Ω
2400W bridge power @ 8Ω
Efficient Class-D amplifier architecture
Lightweight 1U 19" rack-mountable design
Stereo, Parallel Mono and Bridge Mono modes
Switchable 75Hz low-cut filter
Selectable input sensitivity: 0.775V / 1.0V / 1.44V
Built-in limiter for peak output protection
Cool Guide technology for efficient operation
XLR balanced inputs with XLR through outputs
SPK speaker outputs
Compact and lightweight at only 4.60kg

Technical Specifications

Specification Details
Amplifier Type Class-D
RMS Power @ 8Ω 2×800W
RMS Power @ 4Ω 2×1200W
Bridge Power @ 8Ω 1×2400W
Modes Stereo / Parallel Mono / Bridge Mono
Input Sensitivity 0.775V / 1.0V / 1.44V Switchable
Low-Cut Filter 75Hz Switchable
Inputs L+R XLR Female
Through Outputs L+R XLR Male
Speaker Outputs L+R SPK Connectors (+1 for Bridge)
Power Supply 220–240Vac, 50/60Hz IEC
Fuse T10A (20×5mm)
Dimensions 482 × 350 × 44mm
Weight 4.60kg
Rack Format 1U
